Solution · Pacemaker
Cardiac Pacemaker
A miniaturized implantable rhythm-management device for small- and medium-sized dogs and cats, using a low-impedance lead and a long-life battery. Animal studies are complete; a multi-center clinical trial is underway for sick sinus syndrome and AV block.
FEATURES · Technical advantages
Designed around veterinary constraints
Size, longevity, and follow-up were specified with referral cardiology in mind.
Miniaturized generator
An 11 g can reduces pocket tension in cats and toy-breed dogs.
Long-life power system
Projected longevity exceeds eight years at typical veterinary pacing outputs.
Low-impedance electrode
Steroid-eluting bipolar leads are designed to keep capture thresholds stable.
SPECIFICATIONS · Technical specs
Product specifications
| Parameter | Specification |
|---|---|
| Device class | Implantable pulse generator |
| Target species | Dogs and cats, 2–18 kg |
| Indications (trial) | Sick sinus syndrome, high-grade AV block |
| Battery chemistry | Lithium-iodine |
| Lead | Steroid-eluting, low-impedance bipolar |
| Programmer | Wireless veterinary programmer |
| MRI conditionality | Conditional, under evaluation |
| Regulatory status | Multi-center clinical trial |
PRODUCTS · Product models
Products in this solution
Explore the devices that make up this solution line.
Clinical trial · Single chamberPaceVet Single
Mass 11 g · Single chamber VVI · Battery 8 yr+ · Lead <500 Ω · Wireless programmer · In clinical trial
PaceVet Single is a single-chamber implantable pulse generator developed specifically for cats and small dogs. The 11 g titanium can reduces pocket tension in patients where human-derived generators are simply too large, and the lithium-iodine power system projects beyond eight years at typical veterinary pacing outputs. The device is currently in multi-center clinical trials for sick sinus syndrome and high-grade AV block.
View details →
Clinical trial · Dual chamberPaceVet Dual
Mass 14 g · Dual chamber DDD/DDDR · Battery 7 yr+ · Dual bipolar leads · Wireless programmer · In clinical trial
PaceVet Dual is a dual-chamber implantable pulse generator that preserves atrioventricular synchrony in dogs with intact sinus function and conduction block. Rate-responsive DDD pacing maintains physiological chamber timing, which matters for exercise tolerance in working and sporting breeds. The 14 g can and dual low-impedance lead set are in multi-center clinical trials alongside the single-chamber model.
View details →
Diagnostics · Ambulatory ECGWireless Holter Pro
3-channel ECG · 7-day recording · 48 g wearable · 1000 Hz sampling · Wireless sync · Reusable
Wireless Holter Pro is a wearable ambulatory ECG recorder for arrhythmia workup and pacemaker follow-up in dogs and cats. The 48 g harness-mounted unit records three channels continuously for up to seven days, streaming to a clinic dashboard so a cardiologist can review events without recalling the patient. It is the diagnostic front end for the PaceVet implant program.
View details →
